Maverick 13500 HD (EN 14492-1)
The Dragon Winch Maverick 13500 HD (EN 14492-1) is recommended for Recovery Vehicles. Durable and tough due to superior materials and construction methods, the Maverick 13500 HD (EN 14492-1) provides a robust and reliable winching solution in all weather conditions and environments. It is capable of pulling up to 13,000 lb (5,897 kg / 5.9 t). The Maverick 13500 HD (EN 14492-1) comes with a 30m of 10.3mm Steel Cable with Clevis Hook fed through Roller Guides, which are all included. The winch is controlled with a Wired & Wireless Controller. The Maverick 13500 HD (EN 14492-1) comes in 12v and 24v options. The winch comes with a two-year return-to-base warranty.
Key Features
| Pulling Rate | 13500lbs (5897kg) | Weight | 57kg | Braking System | Dynamic |
|---|---|---|---|---|---|
| Rope Length | 31m | Dimensions (w/d/h) | 560mm x 196mm x 267mm | Transmission/Gear System | 3 Stage Planetary |
| Horsepower | 7.8hp | Mounting Screw Spacing | 254mm x 114mm | Gear/Speed Reduction Ratio | 318:1 |
| Power Supply | Electrical (Battery) | Drum Size | 88mm x 225mm | Guide Bar | 4 Roll/Slide |
| Voltage | 12/24v | Feeding Cable | 1.83m | ||
| Control | Remote Control & Wireless Remote Control |
Pack Includes
30m of 10.3mm Steel Cable
Clevis Hook
Control Box
Roller Guides
Mounting Screws
Control Cables
Wired Controller
Wireless Controller
Wireless Controller Batteries
Marker Tab
Manual
Control Options
Wired Remote Control
Built to tough Dragon Winch standards, a wired control gives a simple and totally reliable solution for controlling your winch in extreme conditions.
Wireless Remote Control
Compact, simple and remote to the winch itself, a wireless control option gives the operator greater ability to focus on the vehicle being towed without being restricted by cables.
Comparison
| Maverick 12000 HD (EN 14492-1) | Maverick 13500 HD (EN 14492-1) | |
|---|---|---|
 |  | Pulling Rate | 12000lbs (5443kg) | 13500lbs (6123kg) |
| Horsepower | 7.8hp | 7.8hp |
| Dimensions | 535mm x 160mm x 245mm | 560mm x 196mm x 267mm |
| Voltage Options | 12/24v | 12/24v |
| Rope Type | Wire | Wire |
| Rope Length | 31m | 31m |
| Gear Reduction Ratio | 318:1 | 318:1 |
| Drum Size (Diameter/Length) | 63.5mm x 244mm | 88mm x 225mm |
| Feeding Cable Length | 1.83m | 1.83m |
| Guide Bar | 4 Roll/Slide | 4 Roll/Slide |
| Price | 655.95GBP | 745.95GBP |
